Features:
*7"Total Metal body construction,IP66 rate protection
*2.0MP LTE Solution,22X Optical Zoom,Support 128GB SD Card,
*Support 4G LTE Celluar Support Audio Support APP/PC Remote Control
*8 pcs LED,IR distance up to 120M;
* High definition 2MP/22X Zoom
*Seamless docking with Haikang, dahua, CMS(XM),UC2,
metavision AEVISION, Milestone and other platforms.
*Compatible with Milestone and AXXON platform
*Military grade circuit design,anti-surge, 6000V transient Voltage
sales@veacam.com
| Camera | WVCPTZMC22X2W |
| Sensor | 1/3" CMOS 2MP Hi3516E+SC2322 |
| Output pixel | 1920x1080/30fps |
| 1920x1080/25fps | |
| Lens | 22X f=4.7mm～94mm |
| BLC | Support |
| AGC | Auto/manual |
| WB | Auto/manual/indoor/outdoor |
| S/N Ratio | >50dB |
| Dome | |
| Communications Protocol | TCP/IP,HTTP,NTP,IGMP,DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,HTTPS,P2P |
| Software Control | IE, CMS, Management Platform |
| Video compression | H.264/M-JPEG |
| Mobile View | Android iPhone |
| Rotation Range | Pan:0º~220º , Tilt:-45º~40º |
| Rotation Speed | Pan:0~30°/s , Tilt:0~25º/s |
| Preset Points | 220pcs presets（dwell time 01-60s interval available） |
| Guard Tours | 3 groups( Max.16 points, dwell time user selectable) |
| AB scan range | Any point in range:-45º~40º and 0º~360º |
| AB scan speed | 1-9 grades |
| Operating temperature | Outdoor: -40℃~+60℃ |
| Operation menu | English |
| Lightning Protection | Transient voltage 6000V |
| IR distance | Up to 120 meters |
| 4G&WIFI specs | |
| 4G processor | ZX297520M |
| WIFI Chipset | RTL8192ES-CG |
| Netword mode | FDD-LTE, TDD-LTE, WCDMA/HSPA+, TD-SCDMA, GSM/GPRS/EDGE |
| 4G Working frequency | LTE B1/B3/B8/B38/B39/B40/B41 |
| WCDMA 2100/900MHz | |
| TD-SCDMA B34/B39 | |
| GSM/GPRS/EDGE: 900/ 1800MHz | |
| Speed | FDD-LTE/TDD-LTE: Upward 50M/Down 150Mbps |
| HSPA+: Upward 5.76M/Down 21Mbps | |
| TD-SCDMA: Upward 2.2Mbps/Down 2.8Mbps | |
| WiFi standard | Protocol：802.11b/g/n, Max: 72Mbps |
| WiFi Working frequency | 2412MHz-2472MHz |
| WiFi Safe mode | Open, WPA-PSK, WPA2-PSK |
