Features:


Smart PT AI Camera

2.0 Megapixel, 1080P CMOS,

Pan and Tile adjustment

Max Storage: 128GB TF card

Smart AI Features








sales@veacam.com
  • Details
  • Specification
  • Drawing
  • Enquiry
  • Recommend

Specs

Camera

Sensor

1/3" CMOS

Focal Length

3.6 mm

Aperture

F2.0

Optical Field of View

100° diagonal, 85° horizontal, 48° vertical

Minimum Illumination

0.01 lux

Audio

Input

Built-in microphone

Output

Built-in speaker

Two-way Audio

Full duplex

Audio Compressing

AAC

Video

Video Compressing

H.264, H.265

Lighting Frequency

50 Hz, 60 Hz

Frame Rate

15 fps

Maximum Resolution

1920 x 1080

Light Source For Night Vision

Infrared LED switchable

Network

Wireless Standard

2.4 GHz Wi-Fi (IEEE 802.11 b/g/n)

Protocols Supported

TCP/IP, UDP/IP, DHCP, RTMP, MUTP

IP Address Type

Dynamic IP address

Recording

Recording Method

Alarm triggered recording, and manual recording

Video Storage

Cloud storage, local Micro SD card (up to 128 GB), and mobile phone memory

Function

AI Function

Human detection, vehicle detection, pet snap, motion tracking

Wake-up Method

PIR body induction wake-up and remote wake-up

Alarm Notification

Alarm push by mobile app, white LED flashing and alarm sound warning

Rotation Angle

0° ~ 355° pan, -30° ~ 90° tilt

Indicator

RGB tri-color LED

Interface

Power

Micro USB

Storage

Micro SD card

Key

Reset key

Installation

Installation Method

Wall mount, ceiling mount, desktop

Bracket Type

1/4'' universal screw hole

Environment

Dustproof and Waterproof

N/A

Operating Temperature

-10 ℃ ~ 45 ℃

Storage Temperature

-20 ℃ ~ 60 ℃

Prodoct Dimension

Dimension

70 mm × 85 mm × 105 mm (without bracket)

Bare Weight

185 g

Finished Weight

700 g

Material

ABS + PC

Color

Black, white, grey, yellow, purple, pink optional

Certification

Certification

CEFCC
