Features:
* 6 pcs LED,IR distance up to 60~80M;
* High definition 2MP, 22X Zoom
* Intelligent IR illumination & power consumption is variable, dependant the zoom facto
*Seamless docking with Haikang, dahua, CMS(XM),UC2, metavision
AEVISION, Milestone and other platforms.
*Compatible with Milestone and AXXON platform
* Support SD Card Slot, Alarm, Audio
| Camera | ||||
| module NO | WVCPTZ45MB22X2 | WVCPTZ45MB22X5 | WVCPTZ45MB36X2 | WVCPTZ45MB36X5 |
| Sensor | 3516E+SONY307 | 3516D+AR0521 | 3516A+SONY327 | 3516A+SONY335 |
| Optical Zoom | 22X | 22X | 36X | 36X |
| Effective pixels | 2.0MP | 5.0MP | 2.0MP | 5.0MP |
| Output Pixel | 2592x1944、2592x1520、2304x1296、1920x1080、1280x960、1280×720、720×576、640×480 | |||
| Iris | F1.6 ~F2.7 | |||
| Angle of view FOV | H：51.8°（W）～5.86°（T） V：39.1°（W）～4.4°（T） | |||
| Min. illumination | Color: 0.1Lux B/W: 0.01Lux | |||
| BLC | Support | |||
| WB | Indoor/Outdoor/Auto/Manual | |||
| D/N | IR-CUT | |||
| 2D NR | Support | |||
| S/N Ratio | ≥50dB | |||
| Dome | ||||
| Communications Protocol | TCP/IP, HTTP, FTP, RTSP, UPnP, DNS, NTP, RTP, UDP, IGMP | |||
| Storage (optional) | One SD/SDHC card | |||
| Software Control | IE, CMS,UC Management Platform | |||
| Mobile View(optional) | Support Windows, Symbian, iPhone platform smartphone | |||
| Preset Points | 220 | |||
| Guard Tours | 4 groups | |||
| Guard Points | Max.16 points, dwell time user selectable | |||
| Operating temperature | Indoor: 0°~ +40° Outdoor: -40°~ +60° | |||
| Operation menu | Multiple languages for OSD menu, English, Spanish etc | |||
| Pan and Tilt position display | Support | |||
| Auto Control IR LED | PWM | |||
| Support ambient light detection | IR illumination on 1-15 grades selectable; | |||
| LEDs | 6pcs | |||
| IR distance | up to 60 meters | |||
| Support ambient light detection | IR illumination on 1-9 grades selectable; | |||
| Humidity | ≤95% Non Condensing | |||
| Power | DC12V ≤2A/3A | |||
| Consumption | < 22W | |||
| Lightning Protection | Transient voltage 6000V | |||
| Communication mode | RS485 (+/-) | |||
| Connection | Coaxial Cable | |||
| Size/Weight | 1.65KG（N.W）,.2.38KG（G.W） | |||
| Related validation | IP66,CE,FCC,RoHs | |||
| Package Size（CM） | 18.5*18.5*28.5 | |||
| Weight | 2.1KG | |||
| 6Pcs 1Box，Box size | 58*40*31 | |||
| 6Pcs 1Box，Box Weight | 13.5KG | |||
